Quick and easy to maintain thanks to the gravity fed cylinder system.
Now even cafés, restaurants, pastry shops, and gelato soft shops with limited space can delight customers with an excellent gelato or a delicious frozen yogurt, or even a fantastic sorbetto, all thanks to the greatly reduced dimensions of the machine.
Optional configurations
Teorema Remote Control
It gives very important info about the machine, it facilitates the service system and helps the cleaning schedule
Self closing device
The dispenser closes automatically stopping the flow of ice cream, eliminating any waste and preventing mess
Single portions dispensing head
With interchangeable nozzles to make single portions and delights
Features & Benefits
Auto pasteurization
Wash cycles reach up to 42 days
Mixing in tank
Standard, to avoid separation of the mix
Tank
5 liter capacity
Air cooled
Air flow transfers vertically through fresh air suction from the base and hot air exiting to the top
Easy to position
Thanks to the innovative solution the machine can be placed next to other equipment reducing wasted space
Heated cleaning of the cylinder
Possibility of heating the cylinder to simplify cleaning
Extremely reduced dimensions
W. 30 x D. 63 x H. 85 cm
Multifunction display
The machine displays operational parameters: mix temperature, gelato consistency, dispenser ready, and insufficient mix, etc.
Control panel
Multilanguage display
| Technical Characteristics | |
|---|---|
| flavour | 1 |
| Mix Delivery System | Gravity |
| Tank Capacity | |
| lt | 5 |
| Hourly production | |
| Gelato kg/hr | 15 kg. Note that production capacity depends on the mix used and the room temperature. |
| Electrical | |
| Cooling System | Air |
| Hz | 230* |
| Ph | 50* |
| Volt/Hz/Ph | 1* |
| Fuse Size A | 16 |
| Rated Power Input kW | 1,8 |
| Refrigerant | |
| Refrigerant | R452; Alternative solutions available. |
| Dimensions | |
| Net Weight kg | 98 |
| Note | |
| Note | * other voltages and cycles available upon request The 161 G SP is produced by Carpigiani with Quality System UNI EN ISO 9001. All specifications mentioned must be considered approximate; Carpigiani reserves the right to modify, without notice, all parts deemed necessary. |
