LB 202 G

Gelato & Low Overrun Batch Freezer

The most compact standing Batch Freezer to accommodate a range of production needs for Gelato, Sorbet, Premium Custard & low overrun Frozen Desserts for the startup frozen dessert business or commissary.

Performance

Hard-o-Dynamic technology ensures product consistency at different loads.

Can accommodate a range of production needs going from start up Ice Cream shop to restaurant and catering needs.

Self-adjusting scraper blades create creamy texture ideal for Gelato and low overrun Premium Ice Cream or Custard.

Convenience

Smallest Carpigiani floor model.

Electronic touch pad provides operational information.


Opportunity & Savings

Self-adjusting scraper can be replaced without needing a new beater.

Air-cooled version is available.

Hygiene

Door design aids complete extraction, resulting in minimal product residue and flavor overlap.


Technical Characteristics
Beater 4/2 H.P. - Unibody w/ Replaceable blades
Cylinder Capacity
lt 10 quarts (with beater)
Electrical
Condenser Air or Water
Cooling System Water Cooled has water inlets and drain connections in the rear 1/2" MPT;
Hz 60
Ph 3
Volt 208-230
Fuse Size A 30 Amps fuse/breaker size. 22 Running Amps. 1 Feeder.
Refrigerant
Refrigerant R-404A
Dimensions
Dimension at base Depth cm 88.9 cm (35 in)
Dimension at base Height cm 141.2 cm (55 3/8 in)
Dimension at base Width cm 50.4 cm (19 3/4 in)
Net Weight kg 258 kg (560 lbs) net weight; 293 kg (645 lbs) crated weight.
Note
Note All specifications mentioned must be considered approximate; Carpigiani reserves the right to modify, without notice, all parts deemed necessary. This unit may be manufactured in other electrical characteristics and may have additional regulatory agency approvals, please consult the local Carpigiani Distributor. Check name plate for exact electrical data. A dedicated electrical connection is required. Manufactured to be permanently connected. See the Electrical chart for the proper electrical requirements. Consult your local Carpigiani distributor for cord & receptacle specifications as local codes allow.
