Performance and functions
- THREE AUTOMATIC PASTEURIZATION PROGRAMS: Pasteurization 65°C, Pasteurization 85°C and Pasteurization 90°C.
- Spigot: for maximum hygiene, after each extraction the internal piston pushes all the mix back into the tank, eliminating any residue within the pipe.
- Blackout and Water Shortage: in the case of an electrical blackout or shortage of water, when conditions return to normal the machine measures the mix temperature and decides whether to continue the current session or to restart the pasteurization process.
Production | |
---|---|
max. lt | 30 |
min. lt | 15 |
Electrical | |
Condenser | Water** |
Hz | 50* |
Ph | 3* |
Volt | 400* |
Fuse Size A | 16 |
Rated Power Input kW | 3,4 |
Dimensions | |
Dimension at base Depth cm | 85 |
Dimension at base Height cm | 103 |
Dimension at base Width cm | 39 |
Net Weight kg | 140 |
Note | |
Note | Performance values refer to 25°C room temperature and 20°C water temperature in the condenser. * Other voltages and cycles available with surcharge. ** Air condenser available with surcharge. The above dimensions and weight refer to the water cooled version. The Pasto XPL are manufactured by Carpigiani using a UNI EN ISO 9001 Certified Quality System. All specifications mentioned must be considered approximate; Carpigiani reserves the right to modify, without notice, all parts deemed necessary. |
